Description
Dia25mm compact self-adhesive tag with custom aluminum-etched antenna perfectly matched to the substrate for easy attachment. Tuned antenna impedance delivers optimal RF transmission; calibrated to 13.56 MHz (ISO/IEC 14443 A) to power the passive chip reliably. With scratch-resistant coating and temperature & humidity tolerant adhesive substrate, stable communication is guaranteed from -20 ℃ to 60 ℃ for versatile deployment.
Technical Specifications
|
Chip Model |
NTAG 223 DNA |
|
Protocol / Standard |
ISO/IEC 14443A, NFC Forum ,Type 4 Tag |
|
Operating Frequency |
13.56 MHz |
|
Memory Capacity |
144Bytes |
|
Label size |
Dia 25mm |
|
Antenna size |
Dia 22mm |
|
Base material |
Coated paper |
|
Antenna Manufacturing Mothed |
Aluminum etching |
|
Read Range |
1–4 cm |
|
Write Endurance |
100,000 cycles minimum |
Application Scenarios
- Luxury goods, premium alcohol & tobacco, pharmaceuticals: high-level anti-counterfeiting and traceability
- Electronic devices & industrial parts: tamper-proof seals and identity verification
- Access control, digital ID documents, encrypted tickets
- High-value documents & parcels: opening detection and full traceability
